INCH-POUND
A-A-52412A
04 May 2011
SUPERSEDING
A-A-52412
November 3, 1992
COMMERCIAL ITEM DESCRIPTION
INCLINOMETER, BALL STYLE
The General Services Administration has authorized the use of this commercial item
description (CID) as a replacement for MIL-I-62384A(AT) for all federal agencies.
1. SCOPE. This CID covers two types of ball-style inclinometers which are used to indicate the
attitude of the vehicle with respect to the horizontal.
2. CLASSIFICATION. Inclinometers shall be of the types specified as follows (see 7.2
and 7.3):
Type I
-
0 to 20 degrees (°) scale
Type II
-
0 to 10° scale
3. SALIENT CHARACTERISTICS
3.1 Materials and finishes. All materials shall be corrosion-resistant type or suitably protected
to resist corrosion.
3.1.1 Color. The inclinometer shall be dull black except for the rear portion behind the glass
tube and marking which shall be white.
3.2 Damping fluid. The damping fluid shall be colorless and shall not interfere with satisfactory
viewing of the ball.
3.3 Design and construction. The assembly shall be constructed so that no part will work loose
in service and shall be built to withstand the strains, jars, vibrations, and other conditions in
shipping, storage, installation, service, and environment.
Beneficial comments, recommendations, additions, deletions, clarifications, etc. and any data that
may improve this document should be sent to DAMI_STANDARDIZATION@conus.army.mil or
U.S. Army RDECOM, Tank Automotive Research, Development and Engineering Center,
ATTN: RDTA-EN/STND/TRANS MS #268, 6501 E. 11 Mile Road, Warren, MI 48397-5000.
Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 6695
